The fuel tanker semi-trailer is outfitted with a tank for transporting cargos. This tank takes advantage of three-dimensional design. It is made using state-of-the-art processing technique. In addition, the oil trailer is equipped with a technologically advanced chassis to achieve high reliability. It allows cargos to be fast loaded and safely transported, in order to ensure high-quality goods and less labor fatigue.

Basic technical parameters of fuel Tank Semi-trailer :

Purpose

Dangerous cargoes semi-trailer series mainly include chemical liquid and fuel tank semi trailer, it is mainly used

for transportation and storage of chemical liquid products and oil products, widely used in various transportation

units, chemical companies, gas station and other industries.

Basic construction

It mainly consists of vehicle frame, tank, discharge system and some various protective devices, it has reasonable

structure, reliable performance, beautiful appearance, and simple operation etc.

Material related

Tank material according to different transportation medium can choose carbon steel, stainless steel, aluminum,

plastic tank, etc.

Fuel Semi Tank Trailer 40M3

Wheel Base

1310 (mm)

Tyre Specifications

12R22.5

No. Of the Tyres

12 pcsISO Certificated

Axle

13T/ 16T (optional)

No. Of the Axles

3 pcs

Landing Gear

28 ton capacity Fuwa with static capacity of 80T

Suspension

Heavy duty mechanic suspension with 10 pcs leaf spring/Air suspension (optional)

King Pin

2’ and 3.5’ interchangable traction pin

Departure Angle

15

compartment

Optional upon choice

Front/Rear Overhang

1900 mm

Material of the Main Beam

Automatic submerged arc welded

Main beams Q345B/ST52-3, through cross beams Q235

Body material Q235B manganese plates, automatic submerged arc welded

End plate Q235A/6mm steel sheet

Brake System

WABCO RE6 relay valve, T30/30 Spring brake chamber,40L air tanks

Colour

As the buyers’request

Accessories

One tool box ,Two spare tire carriers, Two fire extinguishers

Tanker side thickness

5mm carbon steel

Outside sheet

1.2mm steel sheet

Net Weight

9T

Oil tanker

1000 liters Round Shape

Spare tire carrier

1 set

Electrical System

24V, 7core socket, lights according to European standards.

Tool Box

1 box of standard tools

Manhole cover

500mm manhole cover.2 sets with breather valve.

discharge valve

2-4 set ofΦ100mm discharge valves

discharge pipe

4'' rubber hose ,2 pcs ,6m long

Bottom valve

1-2 sets of bottom valve

Painting

Complete chassis sand blasting to clean rust,1 coat of anticorrosive

prime,2 coats of final paint
